Type PT/HC In-Head Temperature Transmitter
Brand: SOR Inc
Specifications
- Programmable Transmitter - Type PT
- Input-Output isolation - excellent filtering of voltage spikes and elimination of ground loops
- Accepts RTD and T/C inputs
- Full access to all features while in operation
- Selectable sensor break function - upscale or downscale
- Long term stability 0.1% / year
- Fast response - measuring frequency of approximately 6 per second update time down to 170 Milliseconds
- Sensor error correction can be matched
- Easy to use Windows configuration software
- NAMUR compliant
- FM and Cenelec approval
- Hart Programmable - Type HC
- Utilizes Hart protocol for configuration and monitoring; communicates with Hart communicator or modem
- Input-Output isolation eliminates measuring errors due to ground loops
- Long term stability 0.1% / year
- Accepts RTD and T/C inputs
- Sensor error correction compensates for known sensor errors
- Customized 50 point linearization any sensor can be matched
- Selectable sensor break function
- Full access to all features while in operation
- FM & Cenelec approvals
- NAMUR compliant
Specifications
Brand
Accuracy
- ± 0.1 % of Temperature Span
Adjustment Type
- Any Value within Range Limit: Zero Adjustable
- Factory Set (Pre-Set)
Approvals & Certifications
- ATEX: II 1 G
- CENELEC: EEx ia IIC T4-T6
- FM: Class I-III, Div. 1, Groups A, B, C, D
- NAMUR
Cable Type
- Communication Cable
Communication
- HART Protocol - Typical HC
Configuration
- Windows® Configuration Software
Enclosure, Body Material
- Head Typical (Cast, Flip Top): Stainless Steel
- Head Typical: Aluminum (Cast, Flip Top)
- Head Typical: Iron (Cast, Flip Top)
Environmental Protection
- IP66
- IP68
- NEMA 4X
Function
- Sensor Break Function Upscale & Downscale
Indication
- Loop Temperature Indicator
Input
- -10 to 500 mV
Isolation
- 1,500 Vac, 1 Minute
Operating Temperature
- -40° to 85° C (-40° to 185° F)
Output
- 20-4 mA
- 4-20 mA
Power Supply
- 8-30 Vdc
Response Time
- Fast Response: Measuring Frequency of Approximately 6 Per 1 second
RTD Type
- Pt100 (a = 0.00385)
- Pt1000 (a = 0.00385)
Sensor, Probe Connection
- 3-Wire
- 4-Wire
Sensor, Probe Type
- E Thermocouple
- J Thermocouple
- K Thermocouple
- N Thermocouple
- RTD
- R Thermocouple
- S Thermocouple
- T Thermocouple
Span & Zero Adjustments
- 10° C (18° F) for Pt100, Pt1000
- 2 mV for Thermocouple, mV
Stability
- Long Term Stability: 0.1 %/Year
Temperature Range
- RTD Typical: -200° to 1,000° C (-328° to 1,832° F)
Update Time
- Down to 170 milliseconds
