Approvals & Certifications
Cable Type
- Mineral Insulated (MI) Cable
Diameter
- Outer Diameter (OD): 1/8 to 3/8” (3.2 to 9.5 mm)
Junction
- Dual Grounded
- Dual Ungrounded
- Exposed
- Grounded
- Ungrounded
Length
- 12 to 36” (30.48 to 91.44 cm)
Materials of Construction
- Head Typical (Cast, Flip Top): Stainless Steel
- Head Typical (Sanitary): Polypropylene
- Head Typical: Aluminum (Cast, Flip Top)
- Head Typical: Iron (Cast, Flip Top)
- Sheath Material: Alloy 600
- Tube Material: Alumina
- Tube Material: Hexalloy
- Tube Material: Mullite
NPT Connection
- 1” NPT Male
- 1/2” NPT Male
- 1-1/2” NPT Male
- 1-1/4” NPT Male
- 3/4” NPT Male
Process Fitting Details
- Galvanized / Stainless Steel: Nipple / Union
Sensor, Probe Type
- B Thermocouple (Platinum / 30 % Rhodium Platinum / 6 % Rhodium)
- K Thermocouple (Chromel Alumel)
- N Thermocouple (Nicrosil Nisil)
- R Thermocouple (Platinum / 13 % Rhodium Pure Platinum)
- S Thermocouple (Platinum/10 % Rhodium Pure Platinum)
