Approvals & Certifications
Enclosure, Body Material
- 316L Stainless Steel
- Aluminum
- Brass
Operating Temperature
- Gauge with or without Switch: -40° to 93° C (-40° to 200° F)
- Transmitter: -20° to 150° F (-20° to 65° C)
Set Point - Decreasing
- bar: 0 to 1.724
- Inches WC: 0 to 20
- kPa: 0 to 172.4
- psi: 0 to 25
Set Point - Increasing
- bar: 0 to 1.724
- Inches WC: 0 to 20
- kPa: 0 to 172.4
- psi: 0 to 25
Switch Type
- 1 or 2 - SPDT 3 W, 125 Vac/dc, 0.25 A
- 1 or 2 - SPST (Normally Open) 25 W, 240 Vac/dc, 0.5 A
System Pressure
- bar: 200
- kPa: 20,000
- psig: 3,000
